Spicer 6.5-1-533 | (1810) Drive Shaft Flange

Dana

  • $370.98


Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.
Brand Spicer
Series 1810
Actual Hole Diameter (Max) 1.25
Bolt Circle Diameter (B) In. 7.25
Bolt Hole Diameter (In.) .438 - DRILLED
Bore Diameter (D) In. 1.25
Circ Flnge Face To End Of Hub 4
Flange Type Circular
Flange Width Diameter (A) In. 8
Hub Diameter (E) In. 6.375
Material Steel
Number Of Holes 12
Pilot Diameter (C) In. 7.750 - FEMALE
Package Qty 1
Package Type EACH
Weight 16.85 LB
Country of Origin United States
