Spicer 5-1-873 | (1610) Drive Shaft Flange

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

---

Brand	Spicer
Series	1610
Actual Hole Diameter (Max)	3.125
Actual Keyway Width (Max)	0.75
Bolt Circle Diameter (B) In.	6.13
Bolt Hole Diameter (In.)	.375 - DRILLED
Bore Diameter (D) In.	1.25
Circ Flnge Face To End Of Hub	3.5
Flange Type	Circular
Flange Width Diameter (A) In.	6.88
Hub Diameter (E) In.	5.25
Material	Steel
Number Of Holes	8
Pilot Diameter (C) In.	6.625 - FEMALE
Set Screw Hole Diameter In.	0.375
Package Qty	1
Package Type	EACH
Weight	9.98 LB
Country of Origin	United States
