Spicer 3-1-1023-3 | (1350) Drive Shaft Flange

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

---

Brand	Spicer
Series	1350
Actual Hole Diameter (Max)	2.251
Actual Hole Diameter (Min)	2.25
Bolt Circle Diameter (B) In.	3.75
Bolt Hole Diameter (In.)	.438-20 - TAPPED
Bore Diameter (D) In.	2.25
Circ Flnge Face To End Of Hub	3
Flange Type	Circular
Flange Width Diameter (A) In.	4.56
Hub Diameter (E) In.	4.562
Key Width (K) In.	0.625
Material	Steel
Number Of Holes	4
Pilot Diameter (C) In.	2.750 - FEMALE
Set Screw Hole Diameter In.	0.5
Package Qty	1
Package Type	EACH
Weight	4.65 LB
Country of Origin	United States
